By Matt Richards
Bark tanning (aka vegetable tanning) is an ancient method of creating durable, water repellent leather with a lot of body. It can be done to virtually any skin. Commercially it is generally reserved for tanning grain-on leathers from large thick hides such as cattle, horse, buffalo and pig. It has been commonly used for saddles, canteens, stiff shoes, belts, wallets, holsters, harnesses, helmets, pouches, trunks, shields and gun cases. It is used as an integral part of many useful items from bellows, to hinges of trunks, to holding wagon wheels together. You know those beautifully carved holsters and saddles? That’s all done on bark tanned hides.
There seem to be two major schools of bark tanning, historically. There is the style developed by civilized man in ancient Egypt, Rome and Greece….which is what we typically think of as “veg tan”. There is also a style of bark tanning done on thinner, softer hides such as deer and caribou employed by northern tribal peoples such as the Saami (Laplanders), Inuit and Eskimo, and the Chukchee of eastern Russia. This type of bark tanning tends to involve much less soaking time (and thus less ‘tanning’) and a softer finished product. Many people believe that this type of softer bark tan was once common throughout Europe.
It is less common to bark tan furs as the tannins can stain the fur, and tannins add body which is usually undesirable except when it is a hide that is so naturally thin and weak that added body strengthens it. However northern peoples did (and still do) tan furs this way, generally by just applying the tannin to the flesh side and doing it on relatively thin hides. We’ve set up a separate section on the bark tanning techniques of native peoples. In this article we’ll focus on the bark tanning tradition of ‘civilized’ peoples.
“Through-tanned vegetable leathers of appreciable firmness are extant from 1500 BC in Egypt, for example, but even so by modern standards they are lightly-tanned and contain only small amounts of fixed tannin.”
Highly developed bark ‘tanneries’ were common in ancient Greece, Rome and Egypt. The earliest known example of vegetable tanning comes from Gebelein Egypt, a tannery thought to be over 5000 years old. Bark tanned leathers were an important tool in the development of civilization, providing an immensely strong and durable material that was pliable; a very unique and useful combination. Bark tanning continued to be an important and basic trade throughout Europe, North Africa, the Middle East and India until the late 1800’s when cheap modern chemical chrome tanning methods came into widespread use for softer grain leathers, and rubbers and plastics started to replace leather for many uses. Unlike brain tanning, which wasn’t efficient to mechanize, bark tanning was mechanized from a very early date. The need for large quantities of bark to be crushed, and dozens of vats for the long soaks encouraged this.
When the colonists came to North America they brought their leather working skills with them. Bark tanneries were set up in nearly every settlement of the new world because this type of leather was considered a necessity. In 1633, Peter Minuit had the first bark mill in North America built in New Netherland (later New York). It was a stone mill powered by a horse and its creation caused a number of tanneries to begin operation in the area. Bark from the clearing of forests for agriculture was in great supply. The census of 1840 estimated some 8,229 tanneries in operation in the US. Bark tanning continues to be done on a large scale and used throughout the world, though on a much more limited basis than in the past. Modern uses include saddles, harnesses, belts, dog collars, holsters and shoe soles.
“Tannins, generally yellow-white to brown, deepen in color when exposed to light….Because they transform proteins into insoluble products that are resistant to decomposition, tannins are used as tanning agents for leather.”
Tannin is a large, astringent (meaning it tightens pores and draws liquids out), molecule found in plants that bonds readily with proteins. When you apply tannins to your skin you can instantly see the skin contract. Put them in your mouth and your cheeks pucker. Medicinally, tannins are used to draw irritants out of your skin such as the venom from bee stings or poison oak. Next time you get stung, pull some fresh bark off the twig of a nearby tree, chew it up and apply it to the sting. The irritation will go away within seconds. Tannins are also applied to burns to help the healing and to cuts to reduce bleeding.
Another every day interaction with tannin is in tea (from the tea plant….not herb teas). The tradition of adding milk to tea has the added benefit of causing the tannins to bind to the proteins in the milk rather than to the proteins in your liver and kidneys. When you drink tea without milk, you are literally tanning your insides.
Tannins occur in nearly every plant from all over the world, in all climates. It is found in almost any part of the plant, from root to leaves, bark to unripe fruit (ever bitten into an unripe persimmon?). Algae, fungi and mosses do not contain much tannin. Many plants don’t contain a useful amount of tannin. Most trees contain plenty of tannin. It is concentrated in the bark layer where it forms a barrier against microorganisms such as fungi and bacteria (when hides are stuck into tannin baths the bacteria are also killed).
There are two types of tannin: Catechol and Pyrogallol.. By understanding when to blend these together, the expert tanner could reputedly create the appropriate leather for any need: hard and firm, mellow and soft, light or heavy. Until you are an expert and can even notice the differences, I wouldn’t worry about it, but it is interesting to pay attention to as you tan.
Catechols (aka condensed) are more astringent and tan more quickly than the pyrogallols. They deposit a reddish sediment known as ‘reds’ or phlobaphenes. They make leathers of pink, red or dark brown hues, that are more ‘solid’. They also create greenish-black spots on contact with iron. Mimosa, birch, hemlock, quebracho, alder and fir bark contain catechols. Oak bark contains both types.
Pyrogallols (aka hydrolysable) deposit a pale-colored sediment called ‘bloom’ (elegiac acid} which, if deposited in the leather, improves its solidarity, wearing properties and resistance to water. Hence they are favored for sole leather. They are also preferable for leathers intended for bookbinding, upholstery and other purposes where longevity is essential. The resultant leather is of pale color varying from creamy or yellowish to light brown. Pyrogallols make bluish-black spots on contact with iron and resist changes in pH value. Sumac, chestnut, oak galls and oak-wood contain pyrogallols.
|Stats on various tannin sources Oak bark averages 10% tannin. Oak wood = 6%. Oak leather is considered mellow and tight, with a yellow-brown color. There are so many varieties that this surely varies.Fir bark has as much as 11% tannin and yields a yellow/brown leather. Certain willows are considered excellent, yielding a soft and supple leather. It can have 10% tannin. Lotta Rahme says that “birch bark yields a somewhat fragile leather, probably because it dissolves out the hide’s natural greases.” Average tannin equals 12%. It is usually used in combo with other materials and is sought for its high sugar content. Gives a light red-brown color.Alder makes a hard and fragile leather and is often used just to color finished leather. It gives a rust orange to red/brown. The brightest color comes from the bark collected just after the first hard freeze.Hemlock bark contains about 10% tannin. The liquors are bright red and full of acid-forming sugars. Good for both heavy sole as well as lighter fancy leather.Chestnut oak also called rock oak is classified as a white oak and is high in tannin (10%), as well as acid-forming sugars. It is among the most desirable of barks for tanning.|
Typical materials used for bark tanning include any of the oaks, fir, certain willows, chestnut, sumac leaves, oak galls, canaigre root, birch, alder, hemlock. Bearberry (leaves), heather, bloodroot, alfalfa, tea, sweet gale, pomegranate rinds, certain fern’s rhizomes and wood-hops have also been used. In fact, when you peruse the literature, you realize that an enormous amount of plants were at one time or another, in one country or another, important sources of tannin.
In modern times 80% of all commercial bark tanning is done with highly concentrated extracts of Quebracho, Chestnut or Mimosa. These extracts are typically 30% tannin or more, whereas naturally occurring tannin is closer to 10% to 12% of the material. Using these concentrated extracts speeds up the tanning times considerably, although many sources say the resultant leather is of a lower quality.
Collecting: All barks are best collected in the spring when the sap starts to rise in the trees, the leaves are just coming out and the bark will peel easily (a fortunate coincidence). This is when they are most concentrated and the easiest to peel, but you can use bark from any time of year. Tannin is usually concentrated in the inner bark (cambium layer). Supposedly, an older tree has more tannin than a younger one, and the lower parts of the tree contain a higher concentration than the top parts. One source says that fir trees should reach 30 years old before debarking and the best oak trees are between 15 and 30 years. Another source said oaks are best between 30 and 35 years…so I wouldn’t get to caught up in it.
Shredded bark from sawmills sold as garden mulch is excellent for bark tanning (assuming it hasn’t been left out in the rain a bunch).
How Much: It really depends on the quality of your source. Mark Odle suggests that in general it takes about twice the weight of the hide in bark to effect a good tan.
Storing: Bark should be dried out and stored dry. Tannin is water soluble and will be leached out of wood or bark that has been left out in the rain. If kept dry, it can be stored indefinitely without losing its effectiveness. Bark is easier to grind if its dry too.
Please Note: These instructions assume that you understand basic tanning processes. If you don’t, you should get one of the Recommended Books, or take a class.
As in any type of tanning, it is preferable to use hides that have been stored frozen or wet-salted, or are fresh. Dried out hides are harder to re-hydrate and get good penetration by the buck and the bark liquor. For more, see the Storing Hides Tutorial.
Fleshing: Flesh as you would for brain tanning. Be careful not to damage the grain. You do not need to get every last bit of membrane off at first. Some people find it easier to membrane the hide after it has been soaked in the tannin for a few days.
Bucking/Liming: After fleshing, soak the skin in an alkaline solution of hydrated lime, wood-ash lye or commercial lye (see the book Deerskins into Buckskins for thorough directions) until the hair slips super easily. Limed hides, especially if they are limed for extended period of times, tend to come out somewhat less stretchy than bucked hides. This phenomenon has historically been exploited to create firmer leathers. If you don’t want a firmer leather, you are better off bucking. See more below under ‘Rinsing’.
Bucking or liming takes longer than it does to simply prepare a hide for brain tanning. Early on, the hair will pull out of the hide fairly easily, but you want it to be so easy that you can just push the hair out rubbing your hand over the hide. Deer hair slips more easily than many other types of hides.
You do not have to do this step though it is a classic part of the bark tanning process. The alternative, which some native people’s do, is to let the hide “sweat” by letting it decay enough that the hair slips, but that the grain and hide are not marred. If you don’t soak the hides in one of these alkaline solutions, it will take longer for the tannins to penetrate the hide and you will need to use more of them. This is because the alkali clean out a mucus that controls the movement of molecules through the hide.
De-hairing: To remove the hair it is best to use a wooden bar with a dull edge, or something similar. It should be more rounded than what you would use to scrape a brain tan, as you do not want to cut or mar the grain. You do want to remove the epidermis though, which is the dark pigmented layer just below the hair. Sometimes it’ll just brush off with the hair, other times you’ll need to make a conscious effort to remove it. The epidermis contains the pigment and is a darkish gray/black, especially in the summer. If patches of hair will not slip easily, return the hide to the alkaline solution.
Rinsing: When all of the hair and epidermis has been removed, rinse the alkali out of the hide by soaking it in running water for 12 to 72 hours (until all signs of swollen-ness are gone). Lime will leave some calcium in the hide, that to fully remove involves further processes that I prefer to gloss over here. These processes were employed when a limed hide was intended to come out more pliable and historically involved soaking the hide in fermenting materials such as hen or dog dung (known as bating), beer dregs, or fermenting grains (known as drenching). In brain tanning, one does notice that limed hides tend to come out less stretchy than bucked hides, particularly if the hide soaked in the lime for an extended period of time (more than three weeks) See Ancient Skins, Parchments and Leathers, for more on bating and drenching.
The finer the bark is ground up the faster and easier it is to extract the tannin (its a surface area thing). In the old days bark was crushed using a large stone wheel, much like a millstone, powered by an ox or horse. It was ground until it was the consistency of cracked corn, wheat berries, or a coarse powder. Modern folks use grain mills on a coarse setting, chipper/shredders used for making garden mulch, or they use their hatchet as best they can to pulverize the bark into small pieces. It should be emphasized though that the smaller you can get it, the more tannin you’ll get from a given quantity of material. And as mentioned before, buying shredded bark (sold as garden mulch) is an easy and cheap way to go.
It is ideal to use rain or other soft water. Tanneries were traditionally located on rivers and streams because they used so much water. I don’t know if they treated their water to remove minerals. The main reason soft water is preferred is because the minerals will react with the tannic acid and create spots or blemishes on the skin. So will blood, if any has been left in the hide (the iron in blood can react with the tannin to make a black stain). I don’t know of any other functional reason to use soft water… the hide will tan without it.
Tannin is water soluble. The warmer the water you soak the bark in the faster the tannin is extracted. Hot water darkens tannin resulting in a darker colored product. Boiling tannins especially darkens and dulls the color (like adding grays to it). Many sources recommend simmering the bark for several hours. Some traditions have you soak the bark in cold water for a few days to extract the tannin. This gives the lightest color. Your choice. Here are two recipes:
Lotta Rahme: “Fill kettle halfway with bark and totally full with water. Bring it to a boil and let it boil for at least an hour. Taste it. The more bitter and astringent the more tannin…like tea or coffee. Take half the liquor and mix with equal amounts of water for the first bath. Use a plastic or wooden tub.”
Steven Edholm and Tamara Wilder: “Steven and Tamara use 1 to 3 gallons of shredded bark and soft water (rain or snow) to cover, in a 2-5 gallon stainless steel pot for several hours. Iron or aluminum pots will react with the tannic acid and cause stains etc., so don’t use them. Plastic, wood, fiberglass, and masonry tubs are all suitable. Use wooden stirring paddles.”
It is very important to use a very weak solution for your first bath. If the hide is put into a strong tannin bath, the outside gets tanned and shrinks. This inhibits the tannins from penetrating to the center of the hide, leaving the inner parts raw. This is called “dead tanning” or “case hardening”.
The first pouring is too strong so put this aside. Add more water, simmer again and pour off. Many tanners will put this aside too, and use the third extraction and then add up to three parts water to the one part liquor for the first solution.
The ideal bath to start with is one that has already been used for another hide. That way all the large tannin particles have already been used up. This is known as a “spent liquor”. There is another advantage to spent liquors. In an old bark liquor, the bark sugars have fermented, forming lactic and acetic acid, which help remove any traces of lime as well as help preserve the hide.
As previously mentioned, you want to use wooden, plastic or masonry containers to do the soaking in. The bigger the container and the more solution that you have in it, the easier it is to evenly tan the hide. It is best to hang the hide(s) over sticks (crossbars) in the solution with as few folds and wrinkles as possible. If you don’t, you should stir and re-adjust the hide more often.
Put the moist but drained skin in. Stir for the first 10 minutes and then once every 10 minutes for the first hour. Skin should be turned and agitated frequently in the first few days to assure even absorption. Epidermis will block the entry of tannin. If there are white patches it is from epidermis that was left. It must be scraped off, but be careful not to remove the grain. Lotta says that sheepskin epidermis is particularly difficult to get off.
You should use progressively stronger solutions. Different tanners recommend different timings for strengthening the bark solution. In general, you strengthen the liquor as you notice it looking weaker.
Lotta recommends strengthening it after the first several hours, removing the skin and membraning it again at this juncture. Mark Odle moves hides to the second run of liquor in a week or ten days. He then strengthens it weekly until the hide has been soaking for five or six weeks when the liquor can be used at full strength. One rule of thumb seems to be that you can push things faster if you are tanning thinner hides like deer and goat (which Lotta is), and that you need to be extra careful of case hardening with thick skins like cow, buffalo or bull elk.
After you start using full strength solutions, you can use the old bath to boil the new bark in, for added strength. However, bark liquor used as a first bath for skin that was de-haired with lime can contain residual lime and shouldn’t be re-used. It should be thrown out. Once the whole skin has an even brown color, the bark can be left in with the skin, and you can leave it for longer times without stirring. If the hides stay in too weak a bath they begin to rot from the inside.
Mark Odle adds vinegar to further acidify and strengthen the solution. Mark adds three or four gallons to 80 or 100 gallons of liquor. Steven and Tamara used to this, but don’t bother any more.
The solution should develop a somewhat pleasant fermented or vinegar like smell from the fermentation of the bark sugars. Smell can be strong but should never be putrid. A sulpherous smell indicates spoilage. At no time should the hide become slick, slippery or slimy. The texture will change from somewhat slippery to a firmer, textured grain. The pores and grain will become quite distinct. Mold may grow on the surface of the liquor, skim it off or stir it in. It is supposed to be (we haven’t tried this) ok to freeze the skin in between baths.
Generally, to be considered ‘through’ tanned, the color should strike through to the center of the thickest part of the hide. To check this, snip a small piece off the neck. Lotta will also put a little saliva on the section that has been cut. Un-tanned skin will not absorb saliva easily and will appear wet, matted and glistening.
Another test is to fold the skin double two times and press the folded area between your fingers. When unfolded the fold should appear as light dry lines.
Some tanners say that the color should be even from the outer edge to the center. Doug Crist says he only has some color reach the center while the outer edges are much darker (much like the hide pictured above). However, he also says that softening the hide is a fair amount of work like brain tanning, whereas other folks say it should be much easier. This may be a factor of how much tannin you get into the center of the hide.
How long you soak your hide depends on the finished product that you desire. The longer you soak it the more it is “filled” with tannins. Once the color has penetrated to the center, you can either remove it from the solution and proceed to currying, or you can leave it in there longer to produce a ‘fuller’ leather. Getting color to the center of the hide means that some tanning has occurred throughout the hide. But you can always get more tannin to attach itself to the fibers and fill the spaces between the collagen chains. The amount of tannin can reach 50% of the weight of the finished leather.
The fuller the hide becomes, the thicker and less stretchy it gets. These are good qualities for saddles, belts and shoe soles, but may not be as desirable for other uses. Full-tanned hides are also easier to carve designs into the surface of. Contrary to this, one source says that thick hides used for sole-leather are sometimes left with an un-tanned stripe in the center which makes it more water tight and harder. This is also sometimes done for knife-sheaths.
Here are some ballpark figures of how long you should expect to soak your hides:
Mark Odle says deerskin sized hides should remain in a full strength ooze for three or four months in moderate temperatures. Cattle and buffalo will take five or six months. The warmer the temperature the faster the process. Once they are tanned through, there is no problem letting them sit in the bath as they will not rot. Looser fibered skins will take the tan more quickly than the tighter skins.
Lotta Rahme recommends as little as 7-10 days to tan a goatskin through, using around 1 3/4 to 2 1/4 lbs of dried bark. Goatskins are very thin. Cattle and elk, can take half a year or more.
A.B. Farnham: Harness and belting leather takes four 1/2 months (for cow), and 6 1/2 months for sole leather.
“Currying is defined as “the preparation of tanned skins for the purpose of imparting to them the necessary smoothness, color, luster and suppleness”.
Mark Odle, The Book of Buckskinning VII
Traditionally in Europe, currying was carried out by specialized tradesmen in an entirely different shop as it is an art unto itself. How exactly this is done, again depends on what you are looking for in the final product. First we’ll give you the general rundown, and then cite specific methods for specific types of leather.
Once the hide is tanned as thoroughly as you want it, rinse it in fresh water for a couple hours. Between each rinse use a slicker and a beam to squeegee out the liquid. (We’ve done this using our wetscraping tool on the flesh side of the hide, putting a towel between the hide and beam to help protect the grain layer from tearing). Your are trying to remove as much unfixed tannin as possible. A slicker can be a round, smooth rod or a hand-sized, rounded edged slab of glass. Slickers can also have slate, brass, copper or heavy glass blades. You want to be real careful not to tear the grain off.
Next the hide is dried a bit, then greased and softened. Any dyeing should be done before oiling the skin.
A Couple of Dye Recipes
Black, from A.B. Farnham: “A good black may be made by putting clear iron filings in 1/2 gallon of vinegar and letting it stand a few days. Add enough filings from time to time so there will always be some un-dissolved. Sumac solution is made by crumbling ten or fifteen pounds of dried sumac leaves into a barrel containing thirty-five or forty gallons of warm water.” “Stir it well and when cool hang the sides or strips in it for about two days. Plunge and stir frequently and on taking out rinse off any particles of leaves, drain a few minutes and brush over with the iron liquor. Rinse off any excess and put back in the sumac over night. If not black enough the next morning, repeat the brushing with iron liquor and return to the sumac for twelve hours more. On completion, rinse well, scrub with warm water and then wash for some hours with several changes of water.”
Red, from Edna Wilder: “To prepare alder bark, the Eskimos scraped the bark in fine pieces, mixed it with a little water and let the mixture stand for a day or so. If they wanted it darker they would boil it for just a few minutes first. They applied the tanning solution generously to the skin in the evening and let is soak overnight, turning it once. The brightest alder color, came from bark collected just before snow, after the first hard freeze (ed. note: I’ve read this in other sources too). They scraped it off in very fine pieces and rubbed it directly on the skin to be dyed. The dryer the skin the quicker it took the dye. Some skins required two or three applications.”
At this point your bark tanned hide will be whatever color was imparted by the tannins, usually a tan or reddish brown. Once the hide is oiled, this color will darken somewhat. If you want to change the color of the skin, you can soak the hide in any tannin based dye. There is a good chapter on dyeing in Steve & Tamara’s Wetscrape Braintanned Buckskin.
Oiling the bark tanned hide makes it dry softer, darkens it and prevents it from cracking…much like oiling a pair of leather boots. Neatsfoot oil, olive oil, tallow, brains, bear fat and fish oil have been used to finish bark tanned leather. Using tallow (a waxy body fat from deer, elk, cows and other ungulates) imparts a heavier feel and more water resistance to the leather. Using a light oil such as neatsfoot, fish, bear or brains results in a lighter, stretchier leather.
The hide should be damp with all excess water expelled by working it on both sides with the slicker. Stretch the hide in all directions. Oil is then spread evenly on the hide and it is either worked soft as it dries or not depending on the type of leather desired. When the hide is dry, it can be lightly dampened or “damped back” by rolling it up in a damp towel. This process of oiling, working and drying can be repeated until you get the softness you desire. When the hide has dried, any surplus oil or tallow can be removed with a rag. To smooth the flesh side, it can be “sleeked” with a slicker.
A.B. Farnham, describes different finishing methods
To finish sole leather, lay the sides or strips down and press out most of the water by covering with some old dry cloths and treading over the whole surface to compress the fibers, then hang up until they are only damp. While still damp give them a good coat of oil on the grain side only, and hang up again until fully dry. Sole leather can be waterproofed by greasing heavily. Recipe: 3 parts tallow to 1 part fish or neatsfoot oil.
Harness and belting are finished by taking the still quite damp hide, pressing out the rinse water, slick over the grain side thoroughly and give it a liberal coat of neatsfoot or fish oil. Hang up or better, take out, spread smooth and let dry slowly. When dry, damp back by wetting or rolling up in wet burlap until damp and limber all over. Prepare a stuffing of equal parts tallow and neatsfoot oil (or fish). Heat them together, and allow to cool until soft and pasty but not liquid. Apply a thin coating to the grain side while it is warm and hang them up to dry. When dry remove the surplus stuffing by working over the grain side with the slicker. If there isn’t enough grease in the leather yet, dampen back again and repeat the process of greasing, drying and slicking. Finally rub over with sawdust to remove a surplus of the grease.
Softer leathers are finished by oiling the damp leather, stretching out and drying, damping back, slicking, staking and drying. Repeat if necessary. Do not apply tallow or heavy grease to light skins and spend plenty of time slicking and staking it.
“All softening processes begin when the tanned skins are partly dry and are continued until they are fully dry and sufficiently flexible.”
Mildly Soft: Hides that you want mildly flexible can be rolled on a table with the hands using considerable pressure. How you do this rolling will affect the grain’s texture. According to Steven & Tamara, “If the hide is rolled up each way with the grain inside, an “orange-peel” texture results. If the hide is maintained flat or rolled with the grain out, the surface remains flatter.” The grain side can also be rubbed with a weak soap solution and then scrubbed with a piece of glass to produce a tight and shiny grain. In the old days, grain patterns were made with specialized tools called “grain-rollers”.
Softer: Only hides for which you want a soft and stretchy texture are ‘softened’ anything like brain tan is. This is usually limited to thinner skins that haven’t been tanned very ‘full’. They may be softened by drawing them across a dull edge (like a staker) or wire, as well as pulled and stretched by hand. You probably wouldn’t want to use a cable as that will rough up the surface. Up to a point, the more you work it, the softer the finished skin will be. If you have just barely tanned it through, you may need to soften it as rigorously, or nearly so, as you would for brain tanning. That is Doug & Lynx’s experience at least.
